HILUX PATROL


ARMORED HILUX PATROL

Armored Toyota Landcruiser 78 hardtop is for those who is demanding a phenomenal driving experience on tough terrains that provides stability at all times with less running cost
Armored Landcruiser 78 Hardtop,- Landcruiser is the proven ‘King off-the-Road’.The Landcruiser 78 hardtop is ready to withstand the harshest road and weather conditions. Artan’s armored Toyota Landcruiser 78 includes full vehicle armoring with certified steel and design to resist external armor without compromising the vehicle’s performance. The high-capacity wheel and tire assembly consist of built-in run-flats. In addition to the left-hand drive Toyota LC 78, Artan can offer right-hand drive upon request. B6 armoring provides 6.5mm steel for defeating major threat levels. Armoring is made to defeat 7.62×51 mm M80 NATO Ball ammunition (U.S. NIJ level III, CEN level B6) and 5.56×45 SS109 ammunition (CEN level B5 and B6) at 0° incidence (90° to the surface) and 10m range according to CEN1063 and CEN1522 and B7 level armoring with 13mm high-quality armour steel defeating the following ammunitions up to the 7.62x51mm P80 Nato Ball (U.S. NIJ level IV, CEN level FB7) at 0° incidence (90° to the surface) and 10m range according to CEN1522. The vehicle is the stable off-road vehicle used in mass quantities by the United Nations and many government officials. The outer appearance of the vehicle does not give any hint of its bulletproof specifications. The vehicle blends into the landscape without being conspicuous, offering confidence and trust on tough rides, from high-speed freeway cruising to off-road in a jungle.
  • Recommended Armoring Protection Level: B6 – B7
  • For Windshield & Door Windows: Multi-layered Ballistic Glass (OEM Inspired).
  • Roof and Floor Armor plating by High-intensity MIG Welding.
  • Multi-layered Polycarbonate Coating for transparent areas.
  • Reinforced Doors and Pillars with Heavy-duty Hinges: Designed for extended longevity and easy maintenance.
  • Protection for the Fuel tank, Tailpipe, Radiator, Battery and the Control Module of the Engine (ECM).
  • Armored bulkhead swing door behind the Land Cruiser`s original rear door with ballistic glass inside.
  • Heavy Duty Suspensions to to cope with the additional weight due to armouring
  •
  • Siren/PA/Intercom system
  • Heavy duty brake system and components
  • Emergency lights system
  • Heavy duty wheels
  • Gun Ports
  • Stobe Lights
  •
Specifications
Year
2018
Make
Toyota
Model
Landcruiser 78 hardtop
Armoring Lvel
B6/B7
Engine
4.5L V8
Transmission
Manual
Horsepower
196HP @ 3300 Rpm
Seating Capacity
9
Wheelbase(mm)
2850
Dimensions(mm)
4990 x 1790 X 2115
